QUIK LOK 100Mtr Drum 2X0.22Mm Balanced Mic Cable – Black
Microphone bulk cable.
QUIK LOK 100Mtr Drum 2X0.22Mm Balanced Mic Cable – Black
Microphone bulk cable.
Inner conductor size: 2 x 0.22 mm² (22 AWG)
Strands x conductor: 7 x 0.20 Bare Copper (BC)
Insulation: PE (Polyethylene) Ø 1.45 mm
Shielding: Bare copper 0.22 drain wire (7 x 0.20) + 100% Conductive PVC
Outer jacket: PVC Polyvinyl Chloride - Hardness grade: 65 Shore
Overall diameter: 6.00 mm
Weight: 39.5 Kg (87.78 lbs) per 1000 m (3280 ft)
Mechanical / Electric Characteristics
Conductor resistance at 20°: <52 Ohm/Km
Conductor/conductor capacitance: 60Pf/m
Insulation resistance at 20°: >5000 Mohm/Km
Working temperature: -30° / +70°
Color: Black
